Common Specification Welded Gabion Basket Mesh
| Common specification of Welded Gabion box | |||
| Wire diameter:2.0-5.0mm | |||
| Nominal box sizes(m) | Mesh size(mm) | No. of diaphragms(no.) | Capacity per box(m3) |
| 1x1x0.5 | 50x50
| 0 | 0.5 |
| 1x1x1 | 0 | 1.0 | |
| 1.5x1x0.5 | 0 | 0.75 | |
| 1.5x1x1 | 0 | 1.5 | |
| 2x1x0.5 | 1 | 1.0 | |
| 2x1x1 | 1 | 2.0 | |
| 3x1x0.5 | 2 | 1.5 | |
| 3x1x1 | 2 | 3.0 | |
| 4x1x0.5 | 3 | 2.0 | |
| 4x1x1 | 3 | 4.0 | |
| Remark:customized size is also available | |||
