PVC Coated Gabion Box for Sale
PVC Coated Gabion Box for Sale
PVC Coated Gabion Box Specifications:
1.Gabion box materials: hot dipped galvanized wire and PVC coated galvanized wire , PVC color : dark green, gray ,black , Galfan Wire
2.Gabion box mesh wire: 2.0mm,2.4mm,2.7mm,3.2mm,3.4mm,4mm
3.Gabion box selvedge wire diameter: 2.4mm,2.7mm,3mm,3.4mm,4mm
4.Gabion box mesh hole : 6*8cm,8*10cm,10*12cm,12*15cm
5.Gabion box Tie wire/lacing wire : 2.2mm, 3%,5%,8% of weight
6.Gabion box Zinc coating : 250-300/m2
7.Gabion box size : 1*1*1m, 2*1*1m,2*1*0.5m,3*1*1m, 4*1*1m,as your requestments.
8.Gabion box With diaphragms
Mesh
Opening
(mm) | WireDiameter
(mm) | Wire Diameter(PVC Coated)
Inner/outside(mm) | Strands |
| 60x80 | 2.0-2.8 | 2.0/3.0-2.5/3.5 | 3 |
| 80x100 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 80x120 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 100x120 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 100x150 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 120x150 | 2.0-4.0 | 2.0/3.0-3.0/4.0 | 3 |
Gabion Box
| Length | Width | Height | Diaphragm | Volume | Tolerance |
| 2.0m | 1.0m | 0.3m | 1 | 0.6m3 | |
| 3.0m | 1.0m | 0.3m | 2 | 0.9m3 | |
| 4.0m | 1.0m | 0.3m | 3 | 0.2m3 | |
| 2.0m | 1.0m | 0.5m | 1 | 1.0m3 | L+/-3% |
| 3.0m | 1.0m | 0.5m | 2 | 1.5m3 | W+/-5% |
| 4.0m | 1.0m | 0.5m | 3 | 2.0m3 | H+/-5% |
| 1.0m | 1.0m | 0.5m | 0 | 1.0m3 | |
| 1.0m | 1.0m | 1.0m | 0 | 1.5m3 | |
| 2.0m | 1.0m | 1.0m | 1 | 2.0m3 | |
| 3.0m | 1.0m | 1.0m | 2 | 3.0m3 | |
| 4.0m | 1.0m | 1.0m | 3 | 4.0m3 | |
PVC Coated Gabion Box for Sale
Packaging & Delivery
Packaging Details:
1. compacted before packaging.
2. Plastic packaging outside and on the pallet. or according to the customers' requirements
3. One 20'container can contain more than 8,000 square meters. 40' container can contain more than 15,000 square meters.
Delivery Detail:
7-15days after prepayment.
Company information
Xinboyuan wire mesh products company has more than 10 years' export experience in wire mesh production. Every week we will get order from customers from all over the world and load more than 5 containers goods. Middle East( Saudi Arabia, Iraq, Jordan, Iran, Dubai, Turkey etc.),Euro (UK, Spain,Greece etc.) South America (Brazil, Mexico, Chile, Peru. Colombia,etc.), Australia, America,Canada.
Our Advantages:
1) we have a professional team with rich experience
2) we have high efficient productive mechanical equipments and technology from Germany.
3) We are local manufacturer .we offer competitive price.
4) We stick to customers' requirements, we believe Excellent product, reasonable price and timely delivery is our service objective.
please contact to us at anytime. And welcome to visit our factory!
Anping Xinboyuan Wire Mesh Products Co.,Ltd
Address: 2217 room,Binjiangyougu building, qiaoxi district ,shijiazhuang city,hebei province,China
Contact person: Emily
Tel: +8613292878767
Mobile: +86-13292878767
Fax: +86-318-7637111
what's app/skype: +8613292878767
Zip Code: 050000
Email: china@china-wiremesh.com.cn
Website: http://www.china-wiremesh.com.cn
http://www.xby-wiremesh.com
For accurate quotation, the following information would be needed:
1. Hole size:
2. Wire diameter:
3. Selvedge wire:
4. Lacing wire:
5. Surface treatment: hot dipped galvanized, galfan or PVC coated
6. Zinc content:
7. Diaphragm:
8. Length, width, height :
